Common Problem
(1) Are you manufacturer? Do you have factory?We are not Professional manufacturer, but we have more than 10 years experience with excellent manufacturer cooperation in this field.
(2) Will you give me a sample?
You can arrange transportation. We can provide samples.
(3) Do you make label?
Yes, we do. We have laser machine, can laser your logo and sizes on the body of milling cutter, also can print labels.
(4) How about the delivery time?
According to the sizes and quantity, delivery time is different. Usually be 3~5 days. We can tell you exact inventory state if you need.
(5) Can you produce carbide Special Tool?
Yes We can. We can special tool according your drawing and sample.
Introduction of the carbide materials
| Carbide Grade | Technical Details of tungsten carbide rod |
| 10U | Co: 10% WC 89% rare element: 1% HRA: 90.5°Grain Size: 0.75um |
| 12U | Co: 12% WC 85% rare element: 3% HRA: 92.5°Grain Size: 0.4um |
| K40 | Co: 12% WC 84% rare element: 4% HRA: 93°Grain Size: 0.4um |
| K44 | Co: 12% WC 84% rare element: 4% HRA: 93.5°Grain Size: 0.4um |
Short Delivery time
Fast moving items are kept in stock to meet urgent orders.
Air,Courier, Maritime are all available.
Payment
T/T, Western Union, Paypal.etc
STANDARD SIZES
| Order No. | Flute dia (d) | Cutting length ( l ) | Shank dia (D) | Overall length(L) |
| 1.0×3×4D×50L | 1.0 | 3 | 4 | 50 |
| 1.5×4×4D×50L | 1.5 | 4 | 4 | 50 |
| 2.0×6×4D×50L | 2.0 | 6 | 4 | 50 |
| 2.5×7×4D×50L | 2.5 | 7 | 4 | 50 |
| 3.0×8×4D×50L | 3.0 | 8 | 4 | 50 |
| 3.5×10×4D×50L | 3.5 | 10 | 4 | 50 |
| 4.0×11×4D×50L | 4 | 11 | 4 | 50 |
| 4.5×13×6D×50L | 4.5 | 13 | 6 | 50 |
| 5.0×13×6D×50L | 5.0 | 13 | 6 | 50 |
| 5.5×13×6D×50L | 5.5 | 13 | 6 | 50 |
| 6.0×15×6D×50L | 6.0 | 15 | 6 | 50 |
| 6.5×15×8D×60L | 6.5 | 15 | 8 | 60 |
| 7.0×17×8D×60L | 7.0 | 17 | 8 | 60 |
| 7.5×17×8D×60L | 7.5 | 17 | 8 | 60 |
| 8.0×20×8D×60L | 8.0 | 20 | 8 | 60 |
| 8.5×23×10D×75L | 8.5 | 23 | 10 | 75 |
| 9.0×23×10D×75L | 9.0 | 23 | 10 | 75 |
| 9.5×25×10D×75L | 9.5 | 25 | 10 | 75 |
| 10.0×25×12D×75L | 10.0 | 25 | 12 | 75 |
| 10.5×28×12D×75L | 10.5 | 28 | 12 | 75 |
| 11.0×28×12D×75L | 11.0 | 28 | 12 | 75 |
| 11.5×28×12D×75L | 11.5 | 28 | 12 | 75 |
| 12.0×30×12D×75L | 12.0 | 30 | 12 | 75 |
| 13.0×33×16D×100L | 13.0 | 33 | 16 | 100 |
| 14.0×35×16D×100L | 14.0 | 35 | 16 | 100 |
| 15.0×38×16D×100L | 15.0 | 38 | 16 | 100 |
| 16.0×40×16D×100L | 16.0 | 40 | 16 | 100 |
| 17.0×40×20D×100L | 17.0 | 40 | 20 | 100 |
| 18.0×40×20D×100L | 18.0 | 40 | 20 | 100 |
| 19.0×40×20D×100L | 19.0 | 40 | 20 | 100 |
| 20.0×40×20D×100L | 20.0 | 40 | 20 | 100 |
| 25.0×40×25D×100L | 25.0 | 40 | 25 | 100 |
If you want to customized, please feel free to contact me!
