Product Specification
| Raw Material | ||||
| HRC | Meterial | MG Grain Size(μm) | CO(%) | Flexural Strength(N/mm²) |
| 45° | ZK30 | 0.7 | 10 | 3320 |
| 50° | WF25 CB | 0.6 | 10 | 4000 |
| 55° | K44UF Gurhing | 0.5 | 12 | 4300 |
| 65° | CTU08L CERATIZIT | 0.4 | 10 | 3700 |
| Super Coating | ||||
| AlTiN | TiAIN | TiSiN | Nano | |
| Hardness(HV) | 3200 | 2800 | 3600 | 42(GPA) |
| Thickness(μm) | 2.5-3 | 2.5-3 | 3 | 3 |
| Oxidation Temp(ºC) | 900 | 800 | 1000 | 1200 |
| Friction Coeffient | 0.3 | 0.3 | 0.45 | 0.4 |
| Color | Black | Violet | Copper | Blue |
| (Order No) | Cutting | Shank | Flute | A.O.L |
| d | D | l | L | |
| R0.5×2×4D×50L×2F | 1 | 4 | 2 | 50 |
| R0.75×3×4D×50L×2F | 1.5 | 4 | 3 | 50 |
| R1.0×4×4D×50L×2F | 2 | 4 | 4 | 50 |
| R1.25×5×4D×50L×2F | 2.5 | 4 | 5 | 50 |
| R1.5×6×4D×50L×2F | 3 | 4 | 6 | 50 |
| R1.75×7×4D×50L×2F | 3.5 | 4 | 7 | 50 |
| R2.0×8×4D×50L×2F | 4 | 4 | 8 | 50 |
| R2.5×10×6D×50L×2F | 5 | 6 | 10 | 50 |
| R3.0×12×6D×50L×2F | 6 | 6 | 12 | 50 |
| R3.5×14×8D×60L×2F | 7 | 8 | 14 | 60 |
| R4.0×16×8D×60L×2F | 8 | 8 | 16 | 60 |
| R4.5×18×10D×75L×2F | 9 | 10 | 18 | 75 |
| R5.0×20×10D×75L×2F | 10 | 10 | 20 | 75 |
| R5.5×22×12D×75L×2F | 11 | 12 | 22 | 75 |
| R6.0×24×12D×75L×2F | 12 | 12 | 24 | 75 |
| R7.0×28×14D×100L×2F | 14 | 14 | 28 | 100 |
| R8.0×32×16D×100L×2F | 16 | 16 | 32 | 100 |
| R9.0×36×18D×100L×2F | 18 | 18 | 36 | 100 |
| R10×40×20D×100L×2F | 20 | 20 | 40 | 100 |
1.Are you manufacturer? Do you have factory?
We are Professional manufacturer. Our company has been in this for about 5 years and has initially established a benchmark in the industry. We will further consolidate the brand awareness in Changzhou and allow more customers to accept and recognize our products.
2.Does free shipping is possible?
We don't offer free shipping service, but we will give you some discount if you buy large quantity products.
3.Can you send products to our Forwarder in China?
Yes, if you have forwarder in China, i will glad to send products to him/her.
4.Do you make OEM?
Yes, we do. We have laser machine, can laser your logo and sizes on the body of milling cutter, also can print labels.
5.How about the delivery time?
We normally will dispatch your order with in 5-10 working days depends on stock level, as soon as the order is shipped, we will list the tracking number on your order detail page, if there is any problem regarding to the shipping, please feel free to contact us.
6.Can you produce carbide Special Tool?
Yes, we can. Cutters Customized acceptable!?Coated OEM also acceptable.?We also can produce the products which according to your drawing,or the hot designed recommend to you.
